RELEASE DATE: November 10th, 2020
PRICE:
- United States: $299 (Series S) $499 (Series X)
- Eurozone: €299 (Series S) €499 (Series X)
- United Kingdom: £249 (Series S) £449.99 (Series X)
- Canada: $379 CAD (Series S) $599 CAD (Series X)
- Australia & Oceania: AU$499 (Series S) AU$749 (Series X)
- Brazil: R$ 2.799 (Series S) R$ 4.599 (Series X)
XBOX SERIES X
The Xbox Series X is powered by a custom 7 nm AMD Zen 2 CPU with eight cores running at a nominal 3.8 GHz, or when simultaneous multithreading (SMT) is used, at 3.6 GHz. One CPU core is dedicated to the underlying operating system.The graphics processing unit is also a custom unit based on AMD's RDNA 2 graphics architecture. It has a total of 56 compute units (CUs) with 3584 cores, with 52 CUs and 3328 cores enabled, and will be running at a fixed 1.825 GHz. This unit is capable of 12.15 teraflops of computational power.The unit ships with 16GB of GDDR6 SDRAM, with 10GB running at 560GB/s primarily to be used with the graphics system and the other 6GB at 336GB/s to be used for the other computing functions. After accounting for the system software, approximately 13.5GB of memory will be available for games and other applications, with the system software only drawing from the slower pool.The Xbox Series X target performance is to render games at 4K resolution at 60 frames per second, with the console being about four times as powerful as the Xbox One X. The Series X can support up to 120 frames per second, and can render up to 8K resolution.
The Xbox Series X's console form is designed to be unobtrusive and minimalistic. It has a 15.1 cm × 15.1 cm (5.9 in × 5.9 in) footprint and is 30.1 cm (11.9 in) high and weighs 4.45 kg (9.8 lb);while configured in this vertical orientation, the unit can also be used on its side. Its forward-facing features present only the main power button and an Ultra HD Blu-ray drive.The top of the unit is a single powerful fan. Spencer stated that the console is as quiet as Xbox One X. The Series X includes an HDMI 2.1 output, the storage expansion slot, three USB 3.1 ports, and an ethernet port.The console does not include an infrared blaster or HDMI pass-through like the Xbox One line, supporting HDMI-CEC instead. An earlier leak had suggested a TOSLINK port for digital audio, but this was eliminated in the final design.
XBOX SERIES S
The Xbox Series S is comparable in its hardware to the Xbox Series X, similar to how the Xbox One S relates to the Xbox One X, but has less processing power. While it runs the same CPU with slightly slower clock frequencies, it uses a slower GPU, a custom RDNA2 with 20 CUs at 1.55 GHz for 4 TFLOPS, compared to 12 TFLOPS of the Series X. It ships with 10 GB of RAM and a 512 GB SSD storage unit with a raw input/output throughput of 2.4GB/s, and does not include any optical disc drive, thus requiring the user to gain all software from digital distribution. It is intended to render games nominally at 1440p, with support for a 4K upscaler, at 60 frames per second, although it can go as high at 120 frames per second at this resolution. Otherwise, the console has the same functions as the Xbox Series X, including ports, expansions, and game support.
Microsoft designed the Series S to easily fit inside of a small bag or backpack for portability and travel usage. The Series S unit is about 60% smaller by volume than the Series X, measuring 275 by 151 by 63.5 millimetres (10.83 in × 5.94 in × 2.50 in) in its vertical orientation. In this orientation, its large side surface features the major exhaust port for active air cooling, similar to the top surface of the Series X; additional vents are then located on the top of the Series S. The front features one USB connection and a headphone jack. The rear of the console includes the power connector, one HDMI port, two additional USB ports, and an Ethernet port. Like the Series X, the Series S can also be placed horizontally with the exhaust port facing upward to maintain airflow. The Series S will launch in a matte white case along with a matching controller, distinguishing it from the matte black that the Series X will use.
[BOTH DESCRIPTIONS TAKEN FROM THE WIKI]
